Machine Features:

The base casting is processed by a high-precision five-sided gantry machine tool. Milling, drilling, tapping and thread tapping on five sides can be completed in a single clamping setup, which reduces clamping errors and improves machining accuracy.
Bases of model KMH-630 and above adopt the popular inverted T-shaped layout featuring high overall structural rigidity without overturning moment occurring over the full travel range.
The indexing table supports 1° × 360° indexing with a curvic coupling for high positioning accuracy.
The lead screw is fitted with paired 60° angular contact ball bearings, supported at both ends and pre-stretched to guarantee transmission precision.
Heavy-duty high-precision roller linear guides withstand heavy-load cutting and deliver excellent vibration damping performance.
It is equipped with a high-precision spindle made in Taiwan running at standard rotational speeds, fitted with an air curtain protection device to maintain stable spindle accuracy and extend service life.
The spindle is driven by a high-power double-winding high-torque servo motor with strong output torque.
An intermittent centralized lubrication oil supply system delivers oil to each lubrication point in fixed quantities at regular intervals, forming and maintaining an appropriate lubricating oil film on friction pairs.
The tool changing system adopts a cam manipulator tool changer from a well-known Taiwanese brand, offering stable and reliable tool exchange performance.
